Core X

Bundkort - SSI CEB

Intel X299

LGA2066 Socket

1

ASUS

2 x USB 3.1 Gen 1 - intern stik 1 x USB 3.1 Gen 2 - intern stik 1 x seriel - intern stik 1 x Thunderbolt - intern stik 1 x audio - intern stik

SATA-600 -stikforbindelser: 8 x 7-pin Seriel ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 PCIe 3.0 -stikforbindelser: 2 x M.2 PCIe 3.0 -stikforbindelser: 1 x U.2

1 x CPU 8 x DIMM 288-pins 7 x PCIe 3.0 x16 (x16, x16/x16, x16/x16/x16, x16/x16/x16/x16, x16/x8/x8/x8/x8/x8/x8 tilstand)

Intel Rapid Storage Technology

24-pin hovedstrøm-konnektor, 6-pins ATX12V stikforbindelse, 2 x 8-pins ATX12V stikforbindelser

2 x LAN (10Gigabit Ethernet) 4 x USB 3.1 Gen 1 1 x TOSLINK 1 x USB 3.1 Gen 2 1 x USB-C Gen2 1 x audio linje-ud - mini-jack 1 x mikrofon - mini-jack 1 x audio linje-ud (centrum/subwoofer) - mini-jack 1 x audio linje-ud (bagtil) - mini-jack 1 x audio linje-ind - mini-jack

Ikke-ECC

2400 MHz, 2133 MHz, 2666 MHz, 3600 MHz (O.C.), 4000 MHz (O.C.), 4133 MHz (O.C.), 4200 MHz (O.C.)

Intel Extreme Memory Profiles (XMP)

DDR4

Ikke bufferet

137438953472

Flersproget BIOS, ASUS EZ Flash, USB BIOS Flashback

CrashFree BIOS, jack retasking, ASUS Q-Design, ESD Guards, Q-DIMM, ASUS EZ DIY, Q-LED, Q-Slot, ASUS Q-Connector, audio jack detektions teknologi, ASUS EPU (Energy Processing Unit), ASUS Q-Shield, ASUS TPU (TurboV Processing Unit), ASUS DIGI+ VRM, Intel Smart Response Technology, NVIDIA 4-way SLI Technology Support, ASUS 8 Phase CPU Power Design, Q-Code, ASUS 2 Phase DRAM Power Design, AMD 4-vejs CrossFireX teknologisupport, ASUS Enhanced DRAM Overcurrent Protection, ASUS Stainless Steel Back I/O, Dual Intelligent Processors 5, ASUS Overvoltage Protection, ASUS Crystal Sound 3, AURA RGB Lighting Control, ASUS Fan Xpert 4, Intel Optane Memory Ready, ASUS 5X Protection III, ASUS SafeSlot Core, Intel VROC support, ASUS PRO Clock II Technology, Intel Turbo Boost Max Technology 3.0

Intel X550-AT2

2 x 10 Gigabit Ethernet

HD Audio (8-kanaler)

Realtek ALCS1220A

DTS Connect, High Definition Audio, DTS Headphone:X
